Introduction
In the SLR era some people came up with the term “pancake lens” for very thin 40 to 50mm lenses. Because of the short back focus distance of mirrorless cameras it is very hard to make actually useful lenses for them that are as thin as a pancake though, hence Laowa came up with the term “cookie lens”. This does not only sound more realistic but also pretty cute and the latest addition to this cookie line-up is this Laowa 15mm 5.0. Usually new features are reserved for expensive top-of-the-line products, but this lens already marks a very important point in Laowa’s history. Let’s have a closer look!
The lens was tested on a 42 Mp Sony A7 RII (Sample images with Sony A7 III, Leical M10, and Nikon Zf)
You can see this review as a YouTube video here
Sample Images
Most of the sample images in this review can be found in full resolution here.
Z version on Nikon Zf samples by Martin can be found in high resolution here.
Contents
Specifications / Version History
This Laowa 15mm 5.0 “Cookie” comes for several mounts, I had a look at the E-mount and the M-mount version, while Martin had a look at its Z version. They have the following specifications:
-
- Diameter: 60 mm (E) / 53 mm (M) / 67 mm (Z)
- Field of view: 110° (diagonally)
- Length: 36 mm (E) / 26 mm (M) / 38 mm (Z)
- Weight: 135g (E) / 105g (M) / 154 g (Z) (without hood and caps)
- Filter Diameter: 39 mm
- Number of Aperture Blades: 5 (straight)
- Elements/Groups: 13/9
- Close Focusing Distance: 0.12 m
- Maximum Magnification: 1:5.6
- Mount: Sony-E | Canon-RF | Nikon-Z | L-mount | Leica-M
buy from manufacturer’s shop | B&H | ebay.com | amazon.com for $399 (affiliate links)
Disclosure
This Laowa 15mm 5.0 Cookie was kindly provided free of charge by Laowa for reviewing purpose prior to release.
Handling / Build Quality
E-mount and Z-mount
The focus ring turns exactly 90° from the minimum focus distance (12 cm) to infinity. The focus ring has a rather low resistance and personally I would have hoped for a slightly higher one.
The lens focuses slightly behind infinity which is normal for modern lenses because of mount tolerances.
The lens seems to be made from a mix of metal and polycarbonates, all the writings are engraved and filled with paint.
The lens does not only transmit Exif data to the camera, the aperture diaphragm is also controlled by the camera here. As you can see from the picture above there is also a USB Micro socket for potential firmware updates.
When you turn the focus ring this will automatically bring up the focus assist, but the in-camera distance scale always shows 4.0 m as distance, as there is no elaborate distance encoder.
Also the Z-mount version features electronic contacts to communicate with your camera, and as you can see this lens is also available in silver.
Furthermore the lens features a rubber gasket at the bayonet, this does make the lens a lot harder to mount and unmount though.
A tiny rectangular bayonet type lens hood is also included. I don’t think it will do a lot to reduce lens flares (these hoods rarely do with ultra wide angle lenses) but it does sure look cute. It can also be attached with the logo facing the bottom if you are not a fan of hoods with a flashy logo.
The size difference compared to the much faster Laowa 15mm 2.0 is significant. More importantly, the size difference compared to the only slightly faster 7Artisans 15mm 4.0 and NiSi 15mm 4.0 is just as big.
M-mount
The M-mount version is rangefinder coupled from 0.7 m to infinity but also focuses down to 0.12 m. Resistance is a bit higher compared to the E-mount version I had and it rotates ~100° from 0.12 m to infinity. The helicoid is very steep at closer distances, which makes focusing precisely a bit harder. The focus ring also features a small focus tab at the bottom.
As was already the case for other Laowa M-mount lenses (e.g. 9mm 5.6 or 15mm 2.0 M) there is again a click stop at 0.7 m for you to notice that you are leaving the rangefinder coupled range.
The aperture ring is all manual here and features full-stop click-stops. It rotates ~45° from f/5.0 to f/22.
At the rear bayonet we again see holes to 6-bit code the lens.
When on camera the actual lens is similar in size to the Voigtländer VM 15mm 4.5 II (that one comes with a non-removable hood, which I had professionally cut off).
Vignetting
light falloff
| f/5.0 | 3.2 EV |
| f/5.6 | 2.9 EV |
| f/8.0 | 2.7 EV |
| f/11 - f/22 | 2.6 EV |
The Laowa 15mm 5.0 is a tiny ultra wide angle lens and what all tiny ultra wide angle lenses have in common is not so tiny vignetting. But actually, I was expecting worse here. Don’t get me wrong, 2.6 to 3.2 EV are a lot, but this is not worse than what we have seen from the Voigtländer ultra wide angle lenses. Even the Sony FE 14mm 1.8 GM, which is way bigger, only shows half a stop less vignetting at shared apertures.
It is recommended to have a look at this article first to get an idea how this brightness graph works.
color cast
Some small ultra wide angle lenses show a slight green color cast in the corners of the modern Sony BSI sensors. With normal subjects this is rarely noticeable, but when taking pictures of a snowy landscape or an overcast sky it might be.
I didn’t have any issues with this Laowa 15mm 5.0 though, none of the sample images have been corrected for color cast.
For M-mount users I also have good news here. The similarly small Voigtländer VM 15mm 4.5 II has some issues with the asymmetrical “italian flag” color cast on the M10 (and even more so on older digital M cameras) but this is luckily not the case for this Laowa lens. I cannot guarantee that there will be no color cast on the older M8/M9/M240 models though.
Sharpness
infinity (42mp Sony A7rII, 24mp Leica M10)
I have used a lot of compact lenses and I can’t say that they have usually been over-achievers in this category and also with this Laowa lens I would have hoped for a bit better midframe performance.
All the 15mm E-mount lenses I reviewed so far (e.g. Laowa 15mm 2.0, 7Artisans 15mm 4.0, NiSi 15mm 4.0, Voigtländer 15mm 4.5 E) performed better in this category, but then they are also significantly bigger and heavier.
The performance is not bad in absolute terms, but if you are looking for the highest possible image quality on a high resolution camera this is probably not the lens you are looking for.
close (0.12m, 1:5.6)
Laowa’s ultra wide angle lenses are known for their generous minimum focus distances and this is also the case here. Thanks to the floating elements design the performance is also surprisingly good at these distances. If you stop down to f/8.0 to f/11 even the across frame performance is really good – something only few lenses this wide manage to achieve.
Flare resistance
As always evaluating flare is a complex matter since you can get any lens to look bad if you push it hard enough and a slight change of scenario can affect results a lot.
As is the case for many lenses with the sun outside the frame close to a corner there is a specific position that leads to a huge flare. This is a staged scenario and not something you should be afraid of encountering regularly in the field.
With the sun close to the center of the frame I also encountered double ring flares at all apertures. I found the M-mount version to be more prone to this happening.
Coma
E-mount
Coma is actually well controlled. I had a look at my reviews of the 7Artisans 15mm 4.0, NiSi 15mm 4.0 as well as the Voigtländer 15mm 4.5 E and to my eyes they all show a similar performance in this category.
M-mount
The M-mount version on the Leica M10 actually shows slightly less Coma at f/5.0, but there is of course also a difference in resolution between the Sony A7rII and the Leica M10 that might make the E-mount version look worse here.
The Voigtländer VM 15mm 4.5 II performs similar as does the Laowa 15mm 2.0 M at shared apertures.
Distortion
This Laowa 15mm 5.0 Cookie is not part of Laowa’s “Zero-D” line and we can clearly see why: there is a noticeable amount of wavy distortion.
If I intended to use this lens for architecture shooting I would definitely create a distortion correction profile for it.
Bokeh
If someone was asking for a lens to create a shallow depth of field my first recommendation would not be a 15mm 5.0, but because of its 0.12 m minimum focus distance you can actually create some bokeh when taking pictures of small objects.
Sunstars
No sunstars at f/5.0 and well defined 10-stroke sunstars between f/5.6 and f/22 as we have also seen from other recent Laowa ultra wide angle lenses.
If you want to learn more about sunstars have a look at this article.
Chromatic Aberrations
lateral
There is a notable amount of lateral CA, the one-click correction in Lightroom is still doing a good job though.
longitudinal
As this is a very wide and rather slow lens longitudinal CA (loCA) are nothing to worry about.
Focus Breathing
The Laowa 15mm F5 suffers from a moderate to high amount of focus breathing.
Conclusion
good
|
average
|
not good
|
To make its Voigtländer 15mm 4.5 lens usable on digital sensors, Cosina had to significantly increase its size, which ended in the latest version being much bigger than its predecessors.
Now Laowa managed to create a 15mm 5.0 lens which is just as small as the older version of Voigtländer 15mm 4.5, yet also works properly on digital cameras without color cast issues. And it is cheaper, too!
What are the compromises that were needed for this? All the versions we tried showed a midzone dip, so for best performance on high resolution cameras stopping down is advisable. The flare resistance is also a bit worse compared to the best ultra wide angle lenses we have reviewed.
Still, considering its tiny size and fair price I think this is a very appealing lens to everyone who only rarely needs an ultra wide angle lens and doesn’t need a faster aperture at this focal length. You will always find a place in your bag for this lens and have it with you whenever you may need it. This makes it a great complement to your standard zoom starting at 28, 24 or even 20mm.
buy from manufacturer’s shop | B&H | ebay.com | amazon.com for $399 (affiliate links)
Alternatives
E-mount
All the current 15mm options for E-mount are covered in our Guide to Ultra Wide Angle Lenses for the A7 Series, therefore I will only pick out a few very obvious alternatives to talk about here.
Voigtlander 15mm 4.5 E Super-Wide-Heliar III:
This lens features very similar specifications. Also a small lens, but noticeably bigger than this 15mm 5.0 Laowa. It features electronic contacts to communicate with your camera as well. Does have an annoying non removable lens hood. Distortion is lower.
Also comes in Z-mount. Also with electronic contacts, but unlike the E-mount version with removable lens hood.
buy from amazon.com | amazon.de | B&H | ebay.com | ebay.de (affiliate links) for $699
Laowa 14mm 4.0 FF RL Zero-D:
This used to be the smallest option in this focal length range for E-mount. We had two samples and their optical performance was a bit worse, being part of the Zero-D line this lens has less distortion though. It also has an annoying non-removable lens hood and no electronic contacts.
buy from manufacturer’s online shop | B&H | eBay.com (affiliate links) for $449
The NiSi 15mm 4.0 and the 7Artisans 15mm 4.0 are both significantly bigger, so I don’t consider them actual alternatives.
M-mount
Voigtlander VM 15mm 4.5 Super-Wide-Heliar II:
In terms of dimensions this is the closest competitor in the M-mount world. It does have a lot of color cast issues on all the digital M-mount cameras released before the M11 though. Also has an annoying non-removable lens hood.
buy from ebay.com | ebay.de for about $400 (affiliate links)
Voigtlander VM 15mm 4.5 Super-Wide-Heliar III:
This lens is much bigger than its aforementioned predecessor, but it also managed to get rid of most of its color cast issues – especially on the older Leica-M digital cameras. Still has that annoying non-removable lens hood.
buy from amazon.com | amazon.de | B&H | ebay.com | ebay.de (affiliate links) for $699
Laowa 14mm 4.0 FF RL Zero-D:
In terms of size this sits inbetween the two aforementioned Voigtländer lenses. Its performance didn’t really impress us, it is bigger than this 15mm lens, has a non-removable hood and sells for roughtly the same money. I would rather use this new 15mm 5.0 lens.
buy from manufacturer’s online shop | B&H | eBay.com (affiliate links) for $499
Further Sample Images
Most of the sample images in this review can be found in full resolution here.
Nikon Zf samples by Martin can be found in high resolution here.
